Week 4: Project Summary + Lumion Images

The absence of walls or defining boundaries diminishes the separation between interior and exterior

The Light Rail stop is comprised of rectilinear elements organised in a linear arrangement, much like Van Der Rohe and Zumthor's works

The gaps between the cantilevers create portals of space for light to shine through. The solar panels atop the L-shaped elements provide energy sufficiency for the stop, hence addressing sustainability

Light Rail Stop is situated above Anzac parade on a green overpass

The three textures can be seen on the L-shaped elements and the table-and-chair component

Lumion Folder in Dropbox:

https://www.dropbox.com/sh/i425xpiyb7tcjn2/AAD9o1rRqPbZ2MM30x75SfOla?dl=0

SketchUp Warehouse: Model named- UNSW Light Rail on Anzac Pde Arch Studio 2017

                                     [Model is also in file in dropbox]
